Transparent Plastic Film Roll (CY18T)

Transparent Plastic Film Roll(CY18T)Specifications:

Transparent Plastic Film Roll(CY18T)
Property		Unit	Index					Test method
Thickness		μm	75	100	125	150	188
Thickness tolerance		%	±2	±2	±2	±2	±3	GB/T 13542.2-2009
Tensile strength≥	MD	MPa	160	155	155	150	150
	TD		180	175	170	160	160
Elongation at break ≥	MD	%	110	110	110	110	110
	TD		90	90	90	90	90
Heat shrinkage  (150ºC,15min)≤	MD	%	1.5
	TD		1
Haze ≤		%	6.5	7.5	8.5	10	12	ASTM D 1003
Light transmittance ≥		%	88	88	87	87	87
Surface resistivity≤		Ω	1.0×1011					GB/T 1410-2006
Remark:		All items are delivery inspection.



Product code	Name	Thermal class	Thickness range(μm)	Features	Application
6027D	Clear PET Film	E	50-350	High transparency; Electrical Insulation performance, stamping processing performance; UL listed	Substrate ofadhesive tape, release film and protective film etc.
CY18T	Clear anti-static Pet Film	E	50-188	Transparent film, with excellent anti-static&electrical insulation property	Protective film, insulation spacer,etc.
6027/6027A	PET film for touch switch	E	50-250	Good flatness and dimension stability, excellent electrical insulation performance. 6027 is transparency, 6027A is semi-transparent. UL listed.	Substrate of touch switch, flexible printed circuit, etc.
CY28	Black PET film	E	50-250	Black film with low transmittance and excellent electrical insulation properties. UL listed.	Adhesive tape, electrical insulation spacer, etc.
6023Z	Flame retardant PET film	E	50~250	Clear, milky white, white and black flame retardant PET film, low light transmittance, uniform color and high flame retardant properties, flame retardant rating isVTM-0. It also has excellent electrical insulation and stamping processing properties.UL listed.	Used in fields of electronic industry and building decoration that has higher requirements of flameretardant properties.
CY29H	White opaque PET film	E	50-250	White opaque PET film, excellent electrical insulation performance and mechanical properties	Adhesive tape, electrical insulation spacer, etc.
CY20L	Clear blue PET film for photoelectric display	E	50-250	Clear blue film uniform colored, not fade. Excellent heat resistance and electrical insulation properties.

Contact us if you need More details on Plastic Product. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Pet Film、Polyester Film. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Electronic Materials
